Connect nodes at same level

Given a Binary Tree, The task is to connect all the adjacent nodes at the same level starting from the left-most node of that level, and ending at the right-most node using nextRight pointer by setting these pointers to point the next right for each node.

Examples:

Input:

         1
       / \
     2   3
    / \    \
  4   5   6

Output:

         1—>NULL
       /  \
     2–>3–>NULL
   /   \      \
 4–>5–>6–>NULL

Input:

        10
       /  \
    12   15
    / \    \
  5   4   3

Output:

         10—>NULL
       /     \
    12–>15–>NULL
   /   \      \
 5–>4–>3–>NULL

Below is the idea to solve the problem

Traverse the tree using Breadth first search traversal and maintain a prev pointer initialized with NULL, firstly point it to root then every time a new node is traversed set prev’s nextRight to current node  and move prev to prev’s next.

Follow the below steps to Implement the idea:

  • Initialize a node pointer Prev to NULL and a queue of node pointer Q.
  • Traverse the tree in Breadth-first search order starting from the root.
    • Calculate the size sz of the Q and run a for loop from 0 to sz – 1.
      • If prev is Null then set prev to the current node.
      • Else set prev’s next to the current node and prev to the current node.
    • Set prev’s next to Null and prev to Null.
    • If the current node’s left is not null push it into the queue.
    • If the current node’s right is not null push it into the queue.

Below is the Implementation of the above approach:

C++




/* Iterative program to connect all the adjacent nodes at
 * the same level in a binary tree*/
#include <iostream>
#include <queue>
using namespace std;

// A Binary Tree Node
class node {
public:
    int data;
    node* left;
    node* right;
    node* nextRight;

    /* Constructor that allocates a new node with the
    given data and NULL left and right pointers. */
    node(int data)
    {
        this->data = data;
        this->left = NULL;
        this->right = NULL;
        this->nextRight = NULL;
    }
};
// setting right pointer to next right node
/*
             10 ----------> NULL
            /  \
          8 --->2 --------> NULL
         /
        3 ----------------> NULL
        */
void connect(node* root)
{
    // Base condition
    if (root == NULL)
        return;
    // Create an empty queue like level order traversal
    queue<node*> q;
    q.push(root);
    while (!q.empty()) {
        // size indicates no. of nodes at current level
        int size = q.size();
        // for keeping track of previous node
        node* prev = NULL;
        while (size--) {
            node* temp = q.front();
            q.pop();

            if (temp->left)
                q.push(temp->left);

            if (temp->right)
                q.push(temp->right);

            if (prev != NULL)
                prev->nextRight = temp;
            prev = temp;
        }
        prev->nextRight = NULL;
    }
}

int main()
{
    /* Constructed binary tree is
           10
          /  \
        8     2
       /
      3
      */
    // Let us create binary tree shown above
    node* root = new node(10);
    root->left = new node(8);
    root->right = new node(2);
    root->left->left = new node(3);
    connect(root);
    // Let us check the values
    // of nextRight pointers
    cout << "Following are populated nextRight pointers in "
            "the tree"
            " (-1 is printed if there is no nextRight)\n";
    cout << "nextRight of " << root->data << " is "
         << (root->nextRight ? root->nextRight->data : -1)
         << endl;
    cout << "nextRight of " << root->left->data << " is "
         << (root->left->nextRight
                 ? root->left->nextRight->data
                 : -1)
         << endl;
    cout << "nextRight of " << root->right->data << " is "
         << (root->right->nextRight
                 ? root->right->nextRight->data
                 : -1)
         << endl;
    cout << "nextRight of " << root->left->left->data
         << " is "
         << (root->left->left->nextRight
                 ? root->left->left->nextRight->data
                 : -1)
         << endl;
    return 0;
}
// this code is contributed by Kapil Poonia


Java




import java.io.*;
import java.util.*;
class Node {
    int data;
    Node left, right, nextRight;

    Node(int item)
    {
        data = item;
        left = right = nextRight = null;
    }
}

public class BinaryTree {
    Node root;
    void connect(Node p)
    {
        // initialize queue to hold nodes at same level
        Queue<Node> q = new LinkedList<>();

        q.add(root); // adding nodes to the queue

        Node temp = null; // initializing prev to null
        while (!q.isEmpty()) {
            int n = q.size();
            for (int i = 0; i < n; i++) {
                Node prev = temp;
                temp = q.poll();

                // i > 0 because when i is 0 prev points
                // the last node of previous level,
                // so we skip it
                if (i > 0)
                    prev.nextRight = temp;

                if (temp.left != null)
                    q.add(temp.left);

                if (temp.right != null)
                    q.add(temp.right);
            }

            // pointing last node of the nth level to null
            temp.nextRight = null;
        }
    }

    // Driver program to test above functions
    public static void main(String args[])
    {
        BinaryTree tree = new BinaryTree();

        /* Constructed binary tree is
             10
            /  \
          8     2
         /
        3
        */
        tree.root = new Node(10);
        tree.root.left = new Node(8);
        tree.root.right = new Node(2);
        tree.root.left.left = new Node(3);

        // Populates nextRight pointer in all nodes
        tree.connect(tree.root);

        // Let us check the values of nextRight pointers
        System.out.println(
            "Following are populated nextRight pointers in "
            + "the tree"
            + "(-1 is printed if there is no nextRight)");
        int a = tree.root.nextRight != null
                    ? tree.root.nextRight.data
                    : -1;
        System.out.println("nextRight of " + tree.root.data
                           + " is " + a);
        int b = tree.root.left.nextRight != null
                    ? tree.root.left.nextRight.data
                    : -1;
        System.out.println("nextRight of "
                           + tree.root.left.data + " is "
                           + b);
        int c = tree.root.right.nextRight != null
                    ? tree.root.right.nextRight.data
                    : -1;
        System.out.println("nextRight of "
                           + tree.root.right.data + " is "
                           + c);
        int d = tree.root.left.left.nextRight != null
                    ? tree.root.left.left.nextRight.data
                    : -1;
        System.out.println("nextRight of "
                           + tree.root.left.left.data
                           + " is " + d);
    }
}
// This code has been contributed by Rahul Shakya


Python3




# Iterative program to connect all the adjacent nodes at the same level in a binary tree
class newnode:
    def __init__(self, data):
        self.data = data
        self.left = self.right = self.nextRight = None

#   setting right pointer to next right node

#              10 ----------> NULL
#             /  \
#           8 --->2 --------> NULL
#          /
#         3 ----------------> NULL


def connect(root):

    # Base condition
    if root is None:
        return

    # Create an empty queue like level order traversal
    queue = []
    queue.append(root)
    while len(queue) != 0:

        # size indicates no. of nodes at current level
        size = len(queue)

        # for keeping track of previous node
        prev = newnode(None)
        for i in range(size):
            temp = queue.pop(0)
            if temp.left:
                queue.append(temp.left)
            if temp.right:
                queue.append(temp.right)
            if prev != None:
                prev.nextRight = temp
                prev = temp
        prev.nextRight = None


# Driver Code
if __name__ == '__main__':

    # Constructed binary tree is
    # 10
    #     / \
    # 8     2
    # /
    # 3
    root = newnode(10)
    root.left = newnode(8)
    root.right = newnode(2)
    root.left.left = newnode(3)

    # Populates nextRight pointer in all nodes
    connect(root)

    # Let us check the values of nextRight pointers
    print("Following are populated nextRight",
          "pointers in the tree (-1 is printed",
          "if there is no nextRight)")
    print("nextRight of", root.data, "is ", end="")
    if root.nextRight:
        print(root.nextRight.data)
    else:
        print(-1)
    print("nextRight of", root.left.data, "is ", end="")
    if root.left.nextRight:
        print(root.left.nextRight.data)
    else:
        print(-1)
    print("nextRight of", root.right.data, "is ", end="")
    if root.right.nextRight:
        print(root.right.nextRight.data)
    else:
        print(-1)
    print("nextRight of", root.left.left.data, "is ", end="")
    if root.left.left.nextRight:
        print(root.left.left.nextRight.data)
    else:
        print(-1)

# This code is contributed by Vivek Maddeshiya


C#




// C# program to connect nodes
// at same level
using System;
using System.Collections.Generic;

class Node {
    public int data;
    public Node left, right, nextRight;

    public Node(int item)
    {
        data = item;
        left = right = nextRight = null;
    }
}

public class BinaryTree {
    Node root;
    void connect(Node p)
    {
        // initialize queue to hold nodes at same level
        Queue<Node> q = new Queue<Node>();

        q.Enqueue(root); // adding nodes to the queue

        Node temp = null; // initializing prev to null
        while (q.Count > 0) {
            int n = q.Count;
            for (int i = 0; i < n; i++) {
                Node prev = temp;
                temp = q.Dequeue();

                // i > 0 because when i is 0 prev points
                // the last node of previous level,
                // so we skip it
                if (i > 0)
                    prev.nextRight = temp;

                if (temp.left != null)
                    q.Enqueue(temp.left);

                if (temp.right != null)
                    q.Enqueue(temp.right);
            }

            // pointing last node of the nth level to null
            temp.nextRight = null;
        }
    }

    // Driver code
    public static void Main(String[] args)
    {
        BinaryTree tree = new BinaryTree();

        /* Constructed binary tree is
            10
            / \
        8     2
        /
        3
        */
        tree.root = new Node(10);
        tree.root.left = new Node(8);
        tree.root.right = new Node(2);
        tree.root.left.left = new Node(3);

        // Populates nextRight pointer in all nodes
        tree.connect(tree.root);

        // Let us check the values of nextRight pointers
        Console.WriteLine(
            "Following are populated nextRight pointers in "
            + "the tree"
            + "(-1 is printed if there is no nextRight)");
        int a = tree.root.nextRight != null
                    ? tree.root.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of " + tree.root.data
                          + " is " + a);
        int b = tree.root.left.nextRight != null
                    ? tree.root.left.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of "
                          + tree.root.left.data + " is "
                          + b);
        int c = tree.root.right.nextRight != null
                    ? tree.root.right.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of "
                          + tree.root.right.data + " is "
                          + c);
        int d = tree.root.left.left.nextRight != null
                    ? tree.root.left.left.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of "
                          + tree.root.left.left.data
                          + " is " + d);

        Console.ReadKey();
    }
}

// This code has been contributed by techno2mahi


Javascript




<script>

class Node
{
    constructor(item)
    {
        this.data = item;
        this.left = this.right = this.nextRight = null;
    }
}

let root;

function connect(p)
{
    // initialize queue to hold nodes at same level
        let q = [];

        q.push(root); // adding nodes to the queue

        let temp = null; // initializing prev to null
        while (q.length!=0) {
            let n = q.length;
            for (let i = 0; i < n; i++) {
                let prev = temp;
                temp = q.shift();

                // i > 0 because when i is 0 prev points
                // the last node of previous level,
                // so we skip it
                if (i > 0)
                    prev.nextRight = temp;

                if (temp.left != null)
                    q.push(temp.left);

                if (temp.right != null)
                    q.push(temp.right);
            }

            // pointing last node of the nth level to null
            temp.nextRight = null;
        }
}

// Driver program to test above functions

/* Constructed binary tree is
             10
            /  \
          8     2
         /
        3
        */
root = new Node(10);
root.left = new Node(8);
root.right = new Node(2);
root.left.left = new Node(3);

// Populates nextRight pointer in all nodes
connect(root);

// Let us check the values of nextRight pointers
document.write("Following are populated nextRight pointers in "
                   + "the tree"
                   + "(-1 is printed if there is no nextRight)<br>");
let a = root.nextRight != null ? root.nextRight.data : -1;
document.write("nextRight of " + root.data + " is "
                   + a+"<br>");
let b = root.left.nextRight != null ? root.left.nextRight.data : -1;
document.write("nextRight of " + root.left.data + " is "
                   + b+"<br>");
let c = root.right.nextRight != null ? root.right.nextRight.data : -1;
document.write("nextRight of " + root.right.data + " is "
                   + c+"<br>");
let d = root.left.left.nextRight != null ? root.left.left.nextRight.data : -1;
document.write("nextRight of " + root.left.left.data + " is "
                   + d+"<br>");
// This code is contributed by avanitrachhadiya2155
</script>


Output

Following are populated nextRight pointers in the tree (-1 is printed if there is no nextRight)
nextRight of 10 is -1
nextRight of 8 is 2
nextRight of 2 is -1
nextRight of 3 is -1

Time Complexity: O(N)
Auxiliary Space: O(N)

Connect nodes at the same level using Pre Order Traversal:

This approach works only for Complete Binary Trees. In this method we set nextRight in Pre Order fashion to make sure that the nextRight of parent is set before its children. When we are at node p, we set the nextRight of its left and right children. Since the tree is complete tree, nextRight of p’s left child (p->left->nextRight) will always be p’s right child, and nextRight of p’s right child (p->right->nextRight) will always be left child of p’s nextRight (if p is not the rightmost node at its level). If p is the rightmost node, then nextRight of p’s right child will be NULL.

Follow the below steps to Implement the idea:

  • Set root ->nextRight to NULL.
  • Call for a recursive function of root.
    • If root -> left is not NULL then set root -> left -.> nextRight =  root -> right
    • If root -> right is not NULL then
      • If root -> nextRight is not NULL set root -> right -.> nextRight =  root -> nextRight -> left.
      • Else set root -> right -.> nextRight to NULL.
    • recursively call for left of root
    • recursively call for right of root

Below is the Implementation of the above approach:

C++




// CPP program to connect nodes
// at same level using extended
// pre-order traversal
#include <bits/stdc++.h>
#include <iostream>
using namespace std;

class node {
public:
    int data;
    node* left;
    node* right;
    node* nextRight;

    /* Constructor that allocates a new node with the
    given data and NULL left and right pointers. */
    node(int data)
    {
        this->data = data;
        this->left = NULL;
        this->right = NULL;
        this->nextRight = NULL;
    }
};

void connectRecur(node* p);

// Sets the nextRight of
// root and calls connectRecur()
// for other nodes
void connect(node* p)
{
    // Set the nextRight for root
    p->nextRight = NULL;

    // Set the next right for rest of the nodes
    // (other than root)
    connectRecur(p);
}

/* Set next right of all descendants of p.
Assumption: p is a complete binary tree */
void connectRecur(node* p)
{
    // Base case
    if (!p)
        return;

    // Set the nextRight pointer for p's left child
    if (p->left)
        p->left->nextRight = p->right;

    // Set the nextRight pointer
    // for p's right child p->nextRight
    // will be NULL if p is the right
    // most child at its level
    if (p->right)
        p->right->nextRight
            = (p->nextRight) ? p->nextRight->left : NULL;

    // Set nextRight for other
    // nodes in pre order fashion
    connectRecur(p->left);
    connectRecur(p->right);
}

/* Driver code*/
int main()
{

    /* Constructed binary tree is
                10
            / \
            8 2
        /
        3
    */
    node* root = new node(10);
    root->left = new node(8);
    root->right = new node(2);
    root->left->left = new node(3);

    // Populates nextRight pointer in all nodes
    connect(root);

    // Let us check the values
    // of nextRight pointers
    cout << "Following are populated nextRight pointers in "
            "the tree"
            " (-1 is printed if there is no nextRight)\n";
    cout << "nextRight of " << root->data << " is "
         << (root->nextRight ? root->nextRight->data : -1)
         << endl;
    cout << "nextRight of " << root->left->data << " is "
         << (root->left->nextRight
                 ? root->left->nextRight->data
                 : -1)
         << endl;
    cout << "nextRight of " << root->right->data << " is "
         << (root->right->nextRight
                 ? root->right->nextRight->data
                 : -1)
         << endl;
    cout << "nextRight of " << root->left->left->data
         << " is "
         << (root->left->left->nextRight
                 ? root->left->left->nextRight->data
                 : -1)
         << endl;
    return 0;
}

// This code is contributed by rathbhupendra


C




// C program to connect nodes at same level using extended
// pre-order traversal
#include <stdio.h>
#include <stdlib.h>

struct node {
    int data;
    struct node* left;
    struct node* right;
    struct node* nextRight;
};

void connectRecur(struct node* p);

// Sets the nextRight of root and calls connectRecur()
// for other nodes
void connect(struct node* p)
{
    // Set the nextRight for root
    p->nextRight = NULL;

    // Set the next right for rest of the nodes
    // (other than root)
    connectRecur(p);
}

/* Set next right of all descendants of p.
   Assumption:  p is a complete binary tree */
void connectRecur(struct node* p)
{
    // Base case
    if (!p)
        return;

    // Set the nextRight pointer for p's left child
    if (p->left)
        p->left->nextRight = p->right;

    // Set the nextRight pointer for p's right child
    // p->nextRight will be NULL if p is the right
    // most child at its level
    if (p->right)
        p->right->nextRight
            = (p->nextRight) ? p->nextRight->left : NULL;

    // Set nextRight for other nodes in pre order fashion
    connectRecur(p->left);
    connectRecur(p->right);
}

/* UTILITY FUNCTIONS */
/* Helper function that allocates a new node with the
   given data and NULL left and right pointers. */
struct node* newnode(int data)
{
    struct node* node
        = (struct node*)malloc(sizeof(struct node));
    node->data = data;
    node->left = NULL;
    node->right = NULL;
    node->nextRight = NULL;

    return (node);
}

/* Driver program to test above functions*/
int main()
{

    /* Constructed binary tree is
            10
          /   \
        8      2
      /
    3
  */
    struct node* root = newnode(10);
    root->left = newnode(8);
    root->right = newnode(2);
    root->left->left = newnode(3);

    // Populates nextRight pointer in all nodes
    connect(root);

    // Let us check the values of nextRight pointers
    printf("Following are populated nextRight pointers in "
           "the tree "
           "(-1 is printed if there is no nextRight) \n");
    printf("nextRight of %d is %d \n", root->data,
           root->nextRight ? root->nextRight->data : -1);
    printf("nextRight of %d is %d \n", root->left->data,
           root->left->nextRight
               ? root->left->nextRight->data
               : -1);
    printf("nextRight of %d is %d \n", root->right->data,
           root->right->nextRight
               ? root->right->nextRight->data
               : -1);
    printf("nextRight of %d is %d \n",
           root->left->left->data,
           root->left->left->nextRight
               ? root->left->left->nextRight->data
               : -1);
    return 0;
}


Java




// JAVA program to connect nodes
// at same level using extended
// pre-order traversal
import java.util.*;
class GFG {

    static class node {

        int data;
        node left;
        node right;
        node nextRight;

        /*
         * Constructor that allocates a new node with the
         * given data and null left and right pointers.
         */
        node(int data)
        {
            this.data = data;
            this.left = null;
            this.right = null;
            this.nextRight = null;
        }
    };

    // Sets the nextRight of
    // root and calls connectRecur()
    // for other nodes
    static void connect(node p)
    {
        // Set the nextRight for root
        p.nextRight = null;

        // Set the next right for rest of the nodes
        // (other than root)
        connectRecur(p);
    }

    /*
     * Set next right of all descendants of p. Assumption: p
     * is a complete binary tree
     */
    static void connectRecur(node p)
    {
        // Base case
        if (p == null)
            return;

        // Set the nextRight pointer for p's left child
        if (p.left != null)
            p.left.nextRight = p.right;

        // Set the nextRight pointer
        // for p's right child p.nextRight
        // will be null if p is the right
        // most child at its level
        if (p.right != null)
            p.right.nextRight = (p.nextRight) != null
                                    ? p.nextRight.left
                                    : null;

        // Set nextRight for other
        // nodes in pre order fashion
        connectRecur(p.left);
        connectRecur(p.right);
    }

    /* Driver code */
    public static void main(String[] args)
    {

        /*
         * Constructed binary tree is 10 / \ 8 2 / 3
         */
        node root = new node(10);
        root.left = new node(8);
        root.right = new node(2);
        root.left.left = new node(3);

        // Populates nextRight pointer in all nodes
        connect(root);

        // Let us check the values
        // of nextRight pointers
        System.out.print(
            "Following are populated nextRight pointers in the tree"
            + " (-1 is printed if there is no nextRight)\n");
        System.out.print(
            "nextRight of " + root.data + " is "
            + (root.nextRight != null ? root.nextRight.data
                                      : -1)
            + "\n");
        System.out.print("nextRight of " + root.left.data
                         + " is "
                         + (root.left.nextRight != null
                                ? root.left.nextRight.data
                                : -1)
                         + "\n");
        System.out.print("nextRight of " + root.right.data
                         + " is "
                         + (root.right.nextRight != null
                                ? root.right.nextRight.data
                                : -1)
                         + "\n");
        System.out.print(
            "nextRight of " + root.left.left.data + " is "
            + (root.left.left.nextRight != null
                   ? root.left.left.nextRight.data
                   : -1)
            + "\n");
    }
}

// This code is contributed by umadevi9616


Python3




# Python3 program to connect nodes at same
# level using extended pre-order traversal


class newnode:
    def __init__(self, data):
        self.data = data
        self.left = self.right = self.nextRight = None

# Sets the nextRight of root and calls
# connectRecur() for other nodes


def connect(p):

    # Set the nextRight for root
    p.nextRight = None

    # Set the next right for rest of
    # the nodes (other than root)
    connectRecur(p)

# Set next right of all descendants of p.
# Assumption: p is a complete binary tree


def connectRecur(p):

    # Base case
    if (not p):
        return

    # Set the nextRight pointer for p's
    # left child
    if (p.left):
        p.left.nextRight = p.right

    # Set the nextRight pointer for p's right
    # child p.nextRight will be None if p is
    # the right most child at its level
    if (p.right):
        if p.nextRight:
            p.right.nextRight = p.nextRight.left
        else:
            p.right.nextRight = None

    # Set nextRight for other nodes in
    # pre order fashion
    connectRecur(p.left)
    connectRecur(p.right)


# Driver Code
if __name__ == '__main__':

    # Constructed binary tree is
    # 10
    #     / \
    # 8     2
    # /
    # 3
    root = newnode(10)
    root.left = newnode(8)
    root.right = newnode(2)
    root.left.left = newnode(3)

    # Populates nextRight pointer in all nodes
    connect(root)

    # Let us check the values of nextRight pointers
    print("Following are populated nextRight",
          "pointers in the tree (-1 is printed",
          "if there is no nextRight)")
    print("nextRight of", root.data, "is ", end="")
    if root.nextRight:
        print(root.nextRight.data)
    else:
        print(-1)
    print("nextRight of", root.left.data, "is ", end="")
    if root.left.nextRight:
        print(root.left.nextRight.data)
    else:
        print(-1)
    print("nextRight of", root.right.data, "is ", end="")
    if root.right.nextRight:
        print(root.right.nextRight.data)
    else:
        print(-1)
    print("nextRight of", root.left.left.data, "is ", end="")
    if root.left.left.nextRight:
        print(root.left.left.nextRight.data)
    else:
        print(-1)

# This code is contributed by PranchalK


C#




using System;

// C# program to connect nodes at same level using extended
// pre-order traversal

// A binary tree node
public class Node {
    public int data;
    public Node left, right, nextRight;

    public Node(int item)
    {
        data = item;
        left = right = nextRight = null;
    }
}

public class BinaryTree {
    public Node root;

    // Sets the nextRight of root and calls connectRecur()
    // for other nodes
    public virtual void connect(Node p)
    {

        // Set the nextRight for root
        p.nextRight = null;

        // Set the next right for rest of the nodes (other
        // than root)
        connectRecur(p);
    }

    /* Set next right of all descendants of p.
       Assumption:  p is a complete binary tree */
    public virtual void connectRecur(Node p)
    {
        // Base case
        if (p == null) {
            return;
        }

        // Set the nextRight pointer for p's left child
        if (p.left != null) {
            p.left.nextRight = p.right;
        }

        // Set the nextRight pointer for p's right child
        // p->nextRight will be NULL if p is the right most
        // child at its level
        if (p.right != null) {
            p.right.nextRight = (p.nextRight != null)
                                    ? p.nextRight.left
                                    : null;
        }

        // Set nextRight for other nodes in pre order
        // fashion
        connectRecur(p.left);
        connectRecur(p.right);
    }

    // Driver program to test above functions
    public static void Main(string[] args)
    {
        BinaryTree tree = new BinaryTree();

        /* Constructed binary tree is
             10
            /  \
          8     2
         /
        3
        */
        tree.root = new Node(10);
        tree.root.left = new Node(8);
        tree.root.right = new Node(2);
        tree.root.left.left = new Node(3);

        // Populates nextRight pointer in all nodes
        tree.connect(tree.root);

        // Let us check the values of nextRight pointers
        Console.WriteLine(
            "Following are populated nextRight pointers in "
            + "the tree"
            + "(-1 is printed if there is no nextRight)");
        int a = tree.root.nextRight != null
                    ? tree.root.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of " + tree.root.data
                          + " is " + a);
        int b = tree.root.left.nextRight != null
                    ? tree.root.left.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of "
                          + tree.root.left.data + " is "
                          + b);
        int c = tree.root.right.nextRight != null
                    ? tree.root.right.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of "
                          + tree.root.right.data + " is "
                          + c);
        int d = tree.root.left.left.nextRight != null
                    ? tree.root.left.left.nextRight.data
                    : -1;
        Console.WriteLine("nextRight of "
                          + tree.root.left.left.data
                          + " is " + d);
    }
}

// This code is contributed by Shrikant13


Javascript




<script>
// Javascript program to connect nodes
// at same level using extended
// pre-order traversal

class Node
{
    constructor(item)
    {
        this.data = item;
        this.left = this.right = this.nextRight = null;
    }
}



// Sets the nextRight of
// root and calls connectRecur()
// for other nodes
function connect( p) {
    // Set the nextRight for root
    p.nextRight = null;

    // Set the next right for rest of the nodes
    // (other than root)
    connectRecur(p);
    }

/*
* Set next right of all descendants of p. Assumption: p is a complete binary
* tree
*/
function connectRecur( p) {
    // Base case
    if (p == null)
        return;

    // Set the nextRight pointer for p's left child
    if (p.left != null)
        p.left.nextRight = p.right;

    // Set the nextRight pointer
    // for p's right child p.nextRight
    // will be null if p is the right
    // most child at its level
    if (p.right != null)
        p.right.nextRight = (p.nextRight) != null ? p.nextRight.left : null;

    // Set nextRight for other
    // nodes in pre order fashion
    connectRecur(p.left);
    connectRecur(p.right);
}

// Driver program to test above functions

/* Constructed binary tree is
            10
            / \
        8     2
        /
        3
        */
let root = new Node(10);
root.left = new Node(8);
root.right = new Node(2);
root.left.left = new Node(3);

// Populates nextRight pointer in all nodes
connect(root);

// Let us check the values of nextRight pointers
document.write("Following are populated nextRight pointers in "
                + "the tree"
                + "(-1 is printed if there is no nextRight)<br>");
let a = root.nextRight != null ? root.nextRight.data : -1;
document.write("nextRight of " + root.data + " is "
                + a+"<br>");
let b = root.left.nextRight != null ? root.left.nextRight.data : -1;
document.write("nextRight of " + root.left.data + " is "
                + b+"<br>");
let c = root.right.nextRight != null ? root.right.nextRight.data : -1;
document.write("nextRight of " + root.right.data + " is "
                + c+"<br>");
let d = root.left.left.nextRight != null ? root.left.left.nextRight.data : -1;
document.write("nextRight of " + root.left.left.data + " is "
                + d+"<br>");

// This code is contributed by jana_sayantan.
</script>


Output

Following are populated nextRight pointers in the tree (-1 is printed if there is no nextRight)
nextRight of 10 is -1
nextRight of 8 is 2
nextRight of 2 is -1
nextRight of 3 is -1

Thanks to Dhanya for suggesting this approach.

Time Complexity: O(N)
Auxiliary Space: O(N)

Why doesn’t method 2 work for trees which are not Complete Binary Trees?

Let us consider following tree as an example. In Method 2, we set the nextRight pointer in pre order fashion. When we are at node 4, we set the nextRight of its children which are 8 and 9 (the nextRight of 4 is already set as node 5). nextRight of 8 will simply be set as 9, but nextRight of 9 will be set as NULL which is incorrect. We can’t set the correct nextRight, because when we set nextRight of 9, we only have nextRight of node 4 and ancestors of node 4, we don’t have nextRight of nodes in right subtree of root.


            1
          /    \
        2        3
       / \      /  \
      4   5    6    7
     / \           / \
    8   9        10   11

See Connect nodes at same level using constant extra space for more solutions.

Please write comments if you find anything incorrect, or you want to share more information about the topic discussed above.

Feeling lost in the world of random DSA topics, wasting time without progress? It’s time for a change! Join our DSA course, where we’ll guide you on an exciting journey to master DSA efficiently and on schedule.
Ready to dive in? Explore our Free Demo Content and join our DSA course, trusted by over 100,000 neveropen!

RELATED ARTICLES

Most Popular

Recent Comments
